Scrap Shear HCS



  • Sizes suitable for excavators from 15 to 65 tons
  • Hydraulically controlled, 360° continuously rotatable
  • Highly reliable TORQUE rotary motors with cross-over relief valve (2 motors from HCS 20)
  • Robust, optimally dimensioned hydraulic cylinder with speed valve, mounted upside down, protected piston rod
  • Short cycle times due to speed valve
  • Reinforced jaws made of HARDOX 400-450
  • Wide bushings made of quenched and tempered steel, hardened
  • Induction-hardened pins made of quenched and tempered steel. Pins optimally dimensioned for a long service life.
  • Robust slewing bearing with hardened gear wheel and hardened pinion at hydraulic motor
  • Exchangeable blades made of tool steel, hardened and grinded. kerf adjustable, knives turnable 2 times
  • Exchangeable tip knife made from one part!
  • High closing forces and wide jaw openings
  • Adjustable guides on the left and right of the moving jaw for perfect alignment of the jaws.

Here, you can find further information regarding weights, dimensions, closing forces and hydraulics:

see/print data sheet
